1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 14/96
91 RL15 Relay 15 normally open contact
92 RL15 Common relays 15
93 RL13 Relay 13 normally open contact
4.1.3 Technical specifications
4.1.3.1 Analogue inputs
Analogue conversion type:
10-bit A/D converter
Number of inputs:
10
Type of analogue input:
(configurable via software parameter)
NTC Dixell (-50T110°C; 10KΩ±1% at 25°C)
PTC Dixell(-55T115°C; 990Ω±1% at 25°C)
Digital input (potential free contact)
Voltage: 0 - V, 0 - 5V, 0 - 10V (input resistance 3.7KΩ )
Current: 0 - 20mA, 4 - 20mA (input resistance 100Ω)
Digital input status variation detection time:
100ms (in any case it depends on the cycle time set by the user in the
given application)
Accuracy:
NTC, PTC: ±1°C
0-1V: ±20mV
0-5V: ±100mV
0-10V: ±200mV
2-20mA, 4-20mA: ±0.30mA
Additional power:
+12V: 200mA in total (between +12V and analogue outputs)
+5v: 100mA
Notes:
Any inputs that are powered with a voltage that differs from that supplied
by the device (+12V or +5V) must be powered separately with another
transformer (do not use the same secondary of the controller's power) in
order to prevent the inputs from malfunctioning or being damaged.
4.1.3.2 Digital inputs
Type:
(configurable via software parameter)
Opto-insulated potential free contact
Number of inputs:
20
Digital input status variation detection time:
100ms (in any case it depends on the cycle time set by the user in the
given application)
Notes:
Do not use live contacts in order to prevent the inputs from being
damaged.
4.1.3.3 Analogue outputs
Type:
Non opto-insulated internal power
Number of outputs:
6
Type of analogue output:
(configurable via software parameter)
4 fixed outputs 0-10Vdc (Out1 - Out4)
2 configurable outputs (alternative):
- 0-10Vdc, 4-20mA (Out5 and Out6)
- PWM to be used with Dixell XV modules (TF1 and TF2)
Maximum load:
40mA (Out1 - Out4)
20mA (Out5 and Out6) max with configured outputs 0-10Vdc
400Ω max with configured outputs 4-20mA
22Ω per live analogue output
Accuracy:
Out1 - Out4: ±2% full scale
Out5 – Out6: ±2% full scale
Resolution:
8bit
Notes:
The electrical devices controlled by these analogue outputs must be
powered separately with another transformer (do not use the same
secondary of the controller's power) in order to prevent the outputs from
malfunctioning or being damaged.
