1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 21/96
93 C Potential free contact (MAX 6A)
94 RS485 Master RS485 Master connection (-)
95 RS485 Master RS485 Master connection (+)
96 RS485 Master RS485 Master connection (insulated gnd)
97 RS485 Slave RS485 Slave connection (-)
98 RS485 Slave RS485 Slave connection (+)
99 RS485 Slave RS485 Slave connection (insulated gnd)
100 CAN Bus CAN Bus connection (+), not open
101 CAN Bus CAN Bus connection (-), not open
102 CAN Bus CAN Bus connection (insulated gnd), not open
103 Remote Display Connection for VISOGRAPH remote terminal (Vnr)
104 Remote Display Connection for VISOGRAPH remote terminal (+)
105 Remote Display Connection for VISOGRAPH remote terminal (-)
106 Modem Reset NC relay input to reset an external modem (24Vac/dc)
107 Modem Reset NC relay output to reset an external modem (24Vac/dc)
4.2.3 Technical specifications
4.2.3.1 Analogue inputs
Analogue conversion type:
10-bit A/D converter
Number of inputs:
10
Type of analogue input:
(configurable via software parameter)
NTC Dixell (-50T110°C; 10KΩ±1% at 25°C)
PTC Dixell(-55T115°C; 990Ω±1% at 25°C)
Digital input (potential free contact)
Voltage: 0 - V, 0 - 5V, 0 - 10V (input resistance 3.7KΩ )
Current: 0 - 20mA, 4 - 20mA (input resistance 100Ω)
Digital input status variation detection time:
100ms (in any case it depends on the cycle time set by the user in the
given application)
Accuracy:
NTC, PTC: ±1
℃
0-1V: ±20mV
0-5V: ±100mV
0-10V:±200mV
2-20mA, 4-20mA: ±0.30mA
Additional power:
+12V: 200mA in total
+5v: 100mA
Notes:
Any inputs that are powered with a voltage that differs from that supplied
by the device (+12V or +5V) must be powered separately with another
transformer (do not use the same secondary of the controller's power) in
order to prevent the inputs from malfunctioning or being damaged.
4.2.3.2 Digital inputs
Type:
(configurable via software parameter)
Opto-insulated potential free or live contact (24Vac/dc)
External power 24Vac/dc ±20%
Number of inputs:
20
Digital input status variation detection time:
100ms (in any case it depends on the cycle time set by the user in the
given application)
Notes:
If the digital inputs are used with voltage, use another transformer (do not
use the same secondary of the controller's power) in order to prevent the
inputs from malfunctioning or being damaged.
4.2.3.3 Analogue outputs
Type:
Opto-insulated with separate 24Vac/dc power supply
Number of outputs:
6
Type of analogue output:
(configurable via software parameter)
4 fixed outputs 0-10Vdc (Out1 - Out4)
2 configurable outputs 0-10Vdc, 4-20mA (Out5 and Out6)
Maximum load:
40mA (Out1 - Out4)
20mA (Out5 and Out6) max with configured outputs 0-10Vdc
400Ω max with configured outputs 4-20Ma
22Ω per live analogue output
