1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 20/96
26 Out5 Analogue output 5 0 - 10V, 4 - 20mA, Opto-insulated relay
27 Out6 Analogue output 6 0 - 10V, 4 - 20mA, Opto-insulated relay
28 Supply Power for opto-insulated analogue outputs at 24Vac or 24Vdc(-)
29 Supply Power for opto-insulated analogue outputs at 24Vac or 24Vdc(+)
30 GND(-) Common opto-insulated analogue output
40 DI1 Opto-insulated digital input 1
41 DI2 Opto-insulated digital input 2
42 DI3 Opto-insulated digital input 3
43 DI4 Opto-insulated digital input 4
44 DI5 Opto-insulated digital input 5
45 DI6 Opto-insulated digital input 6
46 DI7 Opto-insulated digital input 7
47 DI8 Opto-insulated digital input 8
48 DI9 Opto-insulated digital input 9
49 DI10 Opto-insulated digital input 10
50 GND(-) Reference “-“ for opto-insulated digital inputs 1 to 20 (if inputs 24Vac or 24Vdc)
51 DI11 Opto-insulated digital input 11
52 DI12 Opto-insulated digital input 12
53 DI13 Opto-insulated digital input 13
54 DI14 Opto-insulated digital input 14
55 DI15 Opto-insulated digital input 15
56 DI16 Opto-insulated digital input 16
57 DI17 Opto-insulated digital input 17
58 DI18 Opto-insulated digital input 18
59 DI19 Opto-insulated digital input 19
60 DI20 Opto-insulated digital input 20
61 IDC Common opto-insulated digital inputs 1 to 20 (if potential free inputs)
70 RL1 Relay 1 normally open contact
71 C Common relays 1, 2 and 3 (MAX 6A)
72 RL2 Relay 2 normally open contact
73 RL3 Relay 3 normally open contact
74 C Potential free contact (MAX 6A)
75 C Potential free contact (MAX 6A)
76 RL4 Relay 4 normally open contact
77 RL5 Relay 5 normally open contact
78 RL6 Relay 6 normally open contact
79 RL7 Relay 7 normally open contact
80 C Common relays 4, 5, 6, 7 and 8 (MAX 6A)
81 RL8 Relay 8 normally open contact
82 C Potential free contact (MAX 6A)
83 C Potential free contact (MAX 6A)
84 RL9 Relay 9 normally open contact
85 RL10 Relay 10 normally open contact
86 C Common relays 9 and 10 (MAX 6A)
87 RL11 Relay 11 normally open contact
88 RL12 Relay 12 normally open contact
89 RL13 Relay 13 normally open contact
90 C Common relays 11, 12, 13, 14 and 15 (MAX 6A)
91 RL14 Relay 14 normally open contact
92 RL15 Relay 15 normally open contact
