7.7.2 ELECTRICAL CONNECTIONS
The IPG800 driver can manage the following electronic expansion valves:
Connection numbering SER Sporland SAGINOMIYA EX3 Emerson
EXM/EXL
Emerson
V4 VALVE
ORANGE
ORANGE
WHITE
WHITE
V2 VALVE
RED
RED
BROWN
ORANGE
V3 VALVE
YELLOW
YELLOW
BLACK
YELLOW
V1 VALVE
BLACK
BLACK
BLUE
BLUE
+12V VALVE
(Common)
GRAY GRAY GRAY BROWN
