4.5.3.6 Mechanical specifications
4 DIN module
4.5.3.7 Electrical specifications
Power Supply:
24Vac +10/-15%, 50/60Hz
20 - 36Vdc
Consumption:
from 30VA (Vac), from 25W (Vdc)
Connectors:
Molex connectors with low voltage wiring (for IPG100D)
Phoenix quick coupling connectors for low voltage (for IPG200D)
STELVIO 90° screw connectors for digital outputs (250Vac, 6A max)
Microprocessor:
AT91SAM9260 32-bit 200Mhz
Permanent FLASH memory:
32MB, in 8-bit
RAM:
32MB, in 16
Internal clock:
standard
4.5.3.8 Plastic container
Mount:
On a DIN rail (EN 50022, DIN 43880)
Fastened with screws via the removable plastic flaps.
Material:
PC-ABS Thermoplastic
Self-extinguishing:
V0 (UL94)
Comparative Tracking Index (CTI):
300V
Colour:
Black or White, depending on the model
4.5.3.9 USB-ETHERNET Adapter (Dixell specification)
The 4 DIN range of programmable controllers can be connected to a computer via an external adapter.
This adapter must be used in the processing environment for the application download in the ipro. This
adapter is not set up for fixed or continuous connection. If the adapter should be kept connected
continuously, the room temperature must not exceed 50°C.
