34 AO 3 Analogue output 3 0-10Vdc, 4-20mA
35 Com Analogue output 2-3 common/GND
36 AO 2 Analogue output 2 0-10Vdc, 4-20mA
37 Com Analogue output 1 common/GND (if PWM = VNR)
38 AO 1 Analogue output 1 0-10Vdc, 4-20mA, PWM (if PWM=OUT and 24Vac Power supply)
39 +12V Additional power +12Vdc (output)
40 +5V Additional power +5Vdc (output)
41 gnd GND reference for 5Vdc/12Vdc and analogue inputs (0-20mA, 4-20mA, 0-10Vdc, 0-1Vdc, 0-5Vdc)
42 PB 7 Configurable analogue input 7 (NTC, PTC, 0..20mA, 4..20mA, 0..10V, 0..1V, 0..5V, DI, PT1000)
43 PB 6 Configurable analogue input 6 (NTC, PTC, 0..20mA, 4..20mA, 0..10V, 0..1V, 0..5V, DI, PT1000)
44 Com Probes common (NTC, PTC, PT1000, DI)
45 PB 5 Configurable analogue input 5 (NTC, PTC, DI, PT1000)
46 PB 4 Configurable analogue input 4 (NTC, PTC, DI, PT1000)
47 Com Probes common (NTC, PTC, PT1000, DI)
48 PB 3 Configurable analogue input 3 (NTC, PTC, DI, PT1000)
49 PB 2 Configurable analogue input 2 (NTC, PTC, DI, PT1000)
50 PB1 Configurable analogue input 1 (NTC, PTC, DI, PT1000)
60 Remote Display Vnr Connection for VISOGRAPH-VISOTOUCH remote terminal (Vnr)
61 Remote Display + Connection for VISOGRAPH-VISOTOUCH remote terminal (+)
62 Remote Display - Connection for VISOGRAPH-VISOTOUCH remote terminal (-)
63 RS485 - RS485 Slave connection (-)
64 RS485 + RS485 Slave connection (+)
65 Ser. Port - Serial Port connection (-) / depend on the model it can be LAN or RS485 MASTER
66 Ser. Port + Serial Port connection (+) / depend on the model it can be LAN or RS485 MASTER
67 gnd Ground reference for RS485 and Ser. Port
4.4.3 Technical specifications
4.4.3.1 Analogue inputs
Analogue conversion type:
10-bit A/D converter
Number of inputs:
7
Type of analogue input:
(configurable via software parameter)
NTC Dixell (-50T110°C; 10KΩ±1% at 25°C)
PTC Dixell(-55T115°C; 990Ω±1% at 25°C)
PT1000 Dixell (-100T150°C; 1000Ω±1% at 0°C)
Digital input (potential free contact)
Voltage: 0-1V, 0-5V, 0-10V (input resistance 3.7KΩ )
Current: 0-20mA, 4-20mA (input resistance 100Ω)
Digital input status variation detection time:
100ms (in any case it depends on the cycle time set by the user in the
given application)
Accuracy:
NTC, PTC, PT1000: ±1%
0-1V: ±20mV
0-5V: ±100mV
0-10V:±200mV
0-20mA, 4-20mA: ±0.30mA
Additional power:
+12V: 100mA in total (between +12V and analogue outputs)
+5V: 10mA
Notes:
Any inputs that are powered with a voltage that differs from that supplied
by the device (+12V or +5V) must be powered separately with another
transformer (do not use the same secondary of the controller's power) in
order to prevent the inputs from malfunctioning or being damaged.
