Emerson iPro Series User Manual

1592025700 IPROFAMILY 3.5 stp GB 2016.12.07 iPro Series 69/96
57 DI17 Opto-insulated digital input 17
58 DI18 Opto-insulated digital input 18
59 DI19 Opto-insulated digital input 19
60 DI20 Opto-insulated digital input 20
61 IDC Common opto-insulated digital inputs 1 to 20 (if potential free inputs)
70 RL1 Relay 1 normally open contact
71 RL2 Relay 2 normally open contact
72 RL3 Relay 3 normally open contact
73 C Common relays 1, 2, 3 and 4
74 RL4 Relay 4 normally open contact
75 C Common relays 1, 2, 3 and 4
76 C Common relays 5, 8 and 9
77 RL5 Relay 5 normally open contact
78 RL6 Relay 6 normally open contact
79 RL7 Relay 7 normally open contact
80 RL8 Relay 8 normally open contact
81 RL9 Relay 9 normally open contact
82 RL10 Relay 10 normally open contact
83 C Common relays 6, 7 and 10
84 RL11 Relay 11 normally open contact
85 RL12 Relay 12 normally open contact
86 RL13 Relay 13 normally open contact
87 C Common relays 12, 13 and 15
88 C Common relays 12, 13 and 15
89 C Common relays 11 and 14
90 C Common relays 11 and 14
91 RL14 Relay 14 normally open contact
92 C Common relays 11 and 14
93 RL15 Relay 15 normally open contact
100 CAN Bus CAN Bus connection (+), not open
101 CAN Bus CAN Bus connection (-), not open
102 CAN Bus CAN Bus connection (insulated gnd), not open
103 LAN LAN Connection (+)
104 LAN LAN Connection (-)
