118
Reference Manual
00809-0100-4840, Rev CB
Appendix F: Programming the 3102 and 3105 using HART
February 2015
Programming the 3102 and 3105 using HART
and indicate when the connection is made. If the Field Communicator fails to connect, it
indicates that no device was found. If this occurs, check the lead connections and re-try.
A full menu map showing how to access transmitter parameters using the Field Communicator
is in Appendix E: Field Communicator Menus.
F.2 Command parameters
F.2.1 Base units
When the transmitter is shipped from the factory, the
default factory setting for Base Units is “metric” or “imperial
ft” depending on the model order code
(see "Ordering information" on page 87).
Note
Keep a record of your programmed settings. Changing base units resets parameters to their
default factory settings in the appropriate units.
Field Communicator
To view or change the transmitter base units
1. From the Home screen, select 3: Service Tools.
2. Select 4: Maintenance.
3. Select 3: Utilities.
4. Select 3: Set Base Units.
5. Use the up and down navigation keys to select new base units, and then save the
selection by selecting “ENTER”.
6. Select “ENTER” to select 1: Yes (in response to Are you sure?”).
7. Use the left navigation key to return to the previous menu.
Note
When messages appear, take appropriate action if needed and select “OK”.
Fast Keys
3, 4, 3, 3
Set Base Units (ft)
m
ft
in
ft
ENTER
ABORT
(Field Communicator Screen Shown)
