122
Reference Manual
00809-0100-4840, Rev CB
Appendix F: Programming the 3102 and 3105 using HART
February 2015
Programming the 3102 and 3105 using HART
Rosemount 3490 Series Control Unit
To select the Present Depth command
1. From the Main Menu screen, select SETUP
2. Select the transmitter (e.g. “Tx1: 3102”).
3. Select DUTY.
4. Select Present Depth.
5. Follow the on-screen instructions to input the present depth, which will then change
the transmitter’s bottom reference using the calculation.
(If prompted to change the mode to “off-line”, use the Enter key).
6. Select “Quit” to exit to the previous menu.
F.2.4 Learn false echo
The transmitter can be manually told the live Distance (on page 199) is being calculated from a
false target echo and that echo can therefore be ignored.
If there is another false target echo, repeat the learning process again.
A maximum of four false echoes can be learnt.
Field Communicator or AMS Device Manager
To ignore a false target echo
1. From the Home screen, select 2: Configure.
2. Select 2: Manual Setup.
3. Select 6: False Echoes (3105) or
7: False Echoes (3102).
4. Select 6: Learn False Echo.
5. Wait three seconds while the transmitter learns to ignore the false echo.
Note
When messages appear, take appropriate action if needed and select “OK”.
Fast Keys
2, 2, 6 [or 7], 6
Present Depth
Esc=Quit =Edit
1.045m
(Rosemount 3491 Screen Shown)
1. Number of False Echoes
2. Distance D910
3. Echo Size D911
4. Target Echoes D913
5. Clear False Echoes
6. Learn False Echo
7. Auto Tank Map
8. False Echo Data
6. Learn False Echo
SAVE
HOME
HELP
0
10.674 ft
75 %
5
(Field Communicator Screen Shown)
