Emerson Rosemount 3100 Series Reference Manual

Reference Manual
00809-0100-4840, Rev CB
Section 2: Transmitter Overview
February 2015
3
Transmitter Overview
Section 2 Transmitter Overview
The Rosemount 3101, 3102, and 3105 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 3
Components of the transmitter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 4
System architecture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 6
2.1 The Rosemount 3101, 3102, and 3105
The 3101, 3102, and 3105 are 4–20 mA loop-powered level transmitters designed for
continuous liquid level measurements in tanks or open channel flows.
The transmitters can be connected directly to a plant control system, or used with a Rosemount
3490 Series Control Unit for programmable control functionality. The Rosemount 3105 may be
mounted in a hazardous area if powered from a protected power supply.
Figure 2-1. Typical Application using a Rosemount 3100 Series Transmitter
A. Rosemount 3100 Series Transmitter E. Pump
B. Rosemount 3490 Series Control Unit F. Transmitter Bottom Reference
C. 4–20 mA Signal G. 4–20 mA and HART Signal
D. Relay
Note
HART is available on the Rosemount 3102 and Rosemount 3105.
B
A
G
EE
20mA
4mA
F
DD
C
