Reference Manual
00809-0100-4840, Rev CB
Appendix F: Programming the 3102 and 3105 using HART
February 2015
Programming the 3102 and 3105 using HART
F.3.2 Tag (P001)
This is for editing an electronic ‘label’ of up to 8 characters for the transmitter. The tag is
typically a reference number, location, or duty description.
Field Communicator or AMS Device Manager
To view or change the tag
1. From the Home screen, select 2: Configure.
2. Select 2: Manual Setup.
3. Select 4: HART / Identity (3105) or
5: HART / Identity (3102).
4. Select 1: Identity, and then select 1: Tag P001.
5. If required:
(a) Input the new tag, and then select “ENTER” to save it.
(b) Select “Send” or “Apply” to update the transmitter.
Rosemount 3490 Series Control Unit
To view or change the tag
1. From the Main Menu screen, select SETUP.
2. Select the transmitter (e.g. “Tx1: 3102”).
3. Select DUTY, and then select IDENTITY.
4. Select Tag.
5. Follow on-screen instructions to input and save the tag.
6. Select “Quit” to exit to the previous menu.
Fast Keys
2, 2, 4 [or 5], 1, 1
Tag P001
3102
3102
ESC
DEL ENTER
HELP
w
s
q
a
z
Lock
Shift
@ &
á ü
x
e
d
c
r
f
v
t
g
b
y
h
n
u
j
m
*
-
+
/
.
0
7
4
1
8
5
2
9
6
3
i
k
o
l
FN
(Field Communicator Screen Shown)
Tag P001
3102
Esc=Quit =Edit
(Rosemount 3491 Screen Shown)
