Programming the 3102 and 3105 using HART
F.4.18 Hardware rev. (D952)
This is the overall hardware revision number of at time of manufacture.
Field Communicator or AMS Device Manager
To view the hardware revision number
1. From the Home screen, select 1: Overview.
2. Select 3: Shortcuts.
3. Select 1: Device Information (twice).
4. Select 1: Identification.
5. Select 7: Hardware Revision D952.
6. When finished, select EXIT to exit to the previous menu.
Rosemount 3490 Series Control Unit
To view the hardware revision number
1. From the Main Menu screen, select SETUP.
2. Select the transmitter (e.g. “Tx1: 3102”).
3. Select SYSTEM.
4. Select FIXED.
5. Select HART.
6. Select Hardware Rev.
7. When finished, use the ESC key to exit to the previous menu.
Fast Keys
1, 3, 1, 1, 1, 7
Hardware Revision D952
1
EXIT
HELP
(Field Communicator Screen Shown)
(Rosemount 3491 Screen Shown)
