Emerson Rosemount 3100 Series Reference Manual

192
Reference Manual
00809-0100-4840, Rev CB
Appendix F: Programming the 3102 and 3105 using HART
February 2015
Programming the 3102 and 3105 using HART
F.3.45 Minimum temperature (P047)
This is a record of the lowest measured temperature inside the transmitter.
Field Communicator or AMS Device
Manager
To view the minimum temperature
1. From the Home screen, select 2: Configure.
2. Select 2: Manual Setup.
3. Select 8: Set Temperature (3105) or
9: Set Temperature (3102).
4. Select 3: Internal Extremes.
5. Select 4: Minimum Temperature P047.
Rosemount 3490 Series Control Unit
To view the minimum temperature
1. From the Main Menu screen, select MONITOR.
2. Select the transmitter (e.g. “Tx1: 3102”).
3. Select DIAGNOSTICS.
4. Select HISTORY.
5. Select Min Temp.
6. When finished, select EXIT to exit to the previous menu.
Fast Keys
2, 2, 8 [or 9], 3. 4
Minimum Temperature P047
-11 degC
-11
ESC
DEL ENTER
HELP
w
s
q
a
z
Lock
Shift
@ &
á ü
x
e
d
c
r
f
v
t
g
b
y
h
n
u
j
m
*
-
+
/
.
0
7
4
1
8
5
2
9
6
3
i
k
o
l
FN
(Field Communicator Screen Shown)
Min Temp P047
-11 °C
(Rosemount 3491 Screen Shown)
