Emerson Rosemount 3100 Series Reference Manual

131
Reference Manual
00809-0100-4840, Rev CB
Appendix F: Programming the 3102 and 3105 using HART
February 2015
Programming the 3102 and 3105 using HART
F.3 Configuration parameters
F.3.1 Message (P000)
This allows a general 32-character message to be edited (12 characters if using a Rosemount
3490 Series Control Unit). It can be used for any purpose, such as a support contact number or
details of the last programming change.
Field Communicator or AMS Device Manager
To view or change the message
1. From the Home screen, select 2: Configure.
2. Select 2: Manual Setup.
3. Select 4: HART / Identity (3105) or
5: HART / Identity (3102).
4. Select 1: Identity.
5. Select 3: Message P000.
6. If a change is required:
(a) Input the new message, and then select “ENTER” to save it.
(b) Select “Send” or “Apply” to update the transmitter.
Rosemount 3490 Series Control Unit
To view or change the message
1. From the Main Menu screen, select SETUP.
2. Select the transmitter (e.g. “Tx1: 3102”).
3. Select DUTY.
4. Select IDENTITY.
5. Select Message.
6. Follow on-screen instructions to input and save the message.
7. Select “Quit” to exit to the previous menu.
Fast Keys
2, 2, 4 [or 5], 1, 3
Message P000
MESSAGE
MESSAGE
ESC
DEL ENTER
HELP
w
s
q
a
z
Lock
Shift
@ &
á ü
x
e
d
c
r
f
v
t
g
b
y
h
n
u
j
m
*
-
+
/
.
0
7
4
1
8
5
2
9
6
3
i
k
o
l
FN
(Field Communicator Screen Shown)
Message
MESSAGE
Esc=Quit =Edit
P000
(Rosemount 3491 Screen Shown)
