126
Reference Manual
00809-0100-4840, Rev CB
Appendix F: Programming the 3102 and 3105 using HART
February 2015
Programming the 3102 and 3105 using HART
Rosemount 3490 Series Control Unit
To use the simulation tool
1. From the Main Menu screen, select SETUP.
2. Select the transmitter (e.g. “Tx1: 3102”).
3. Select SYSTEM, and then select Simulation.
4. Select a simulation mode.
5. When finished, select “Quit” to exit to the previous menu.
F.2.7 Restar t device
This re-starts the transmitter as if the power has been interrupted.
Field Communicator or AMS Device Manager
To restore the original factory configuration
1. From the Home screen, select 3: Service Tools.
2. Select 4: Maintenance.
3. Select 3: Utilities.
4. Select 1: Restart Device.
5. When the message “About to restart the transmitter” appears, select “OK” to continue
(or “ABORT” to not continue).
6. Select 1: Yes to restart the transmitter.
Note
When messages appear, take appropriate action if needed and select “OK”.
Rosemount 3490 Series Control Unit
To restore the original factory configuration
1. From the Main Menu screen, select SETUP.
2. Select the transmitter (e.g. “Tx1: 3102”).
3. Select SYSTEM, and then select RESTART DEVICE.
4. Follow the on-screen instruction (“Start”) to restart the transmitter.
(Use the Enter ( ) key if prompted to change the mode to “off-line”).
5. Select “Quit” to exit to the previous menu.
Fast Keys
3, 4, 3, 1
SIMULATION
Esc=Quit =Edit
Normal
(Rosemount 3491 Screen Shown)
Utilities
1. Restart Device
2. Load Defaults
3. Set Base Units
1. Restart Device
SAVE
HOME
HELP
(Field Communicator Screen Shown)
Esc=Quit =Start
RESTART DEVICE
(Rosemount 3491 Screen Shown)
