183
Reference Manual
00809-0100-4840, Rev CB
Appendix F: Programming the 3102 and 3105 using HART
February 2015
Programming the 3102 and 3105 using HART
F.3.37 Target pulses (P044)
Target Pulses (P044) is the number of ultrasonic pulses in each burst sent from the transmitter
every second.
The factory default “Automatic” setting allows the transmitter to decide the number of pulses.
Alternatively, select a number in the range 4 to 32.
Note
See Pulses in Use (page 207) for the actual number of pulses used.
Field Communicator or AMS Device
Manager
To view or change the number of pulses
in a burst
1. From the Home screen, select 2: Configure.
2. Select 2: Manual Setup.
3. Select 7: Advanced Processing (3105) or
Select 8: Advanced Processing (3102)
4. Select 5: Set Target Pulses.
5. Select 1: Target Pulses P044.
6. If a change is required:
(a) Select a new setting, and then select “ENTER” to save it.
(b) Select “Send” or “Apply” to update the transmitter.
Rosemount 3490 Series Control Unit
To view or change the number of pulses
in a burst
1. From the Main Menu screen, select SETUP.
2. Select the transmitter (e.g. “Tx1: 3102”).
3. Select ENGINEERING, and then select ADVANCED.
4. Select Target Pulses.
5. Follow the on-screen instructions to edit and save the new setting.
(Use the Enter ( ) key if prompted to change mode to “off-line”).
6. Select “Quit” to exit to the previous menu.
Fast Keys
2, 2, 7 [or 8], 5, 1
Target Pulses P044
AUTOMATIC
27
28
29
30
31
32
AUTOMATIC
AUTOMATIC
ENTER
ESC
(Field Communicator Screen Shown)
Target Pulses P043
Automatic
Esc=Quit =Edit
