Emerson Rosemount 3100 Series Reference Manual

179
Reference Manual
00809-0100-4840, Rev CB
Appendix F: Programming the 3102 and 3105 using HART
February 2015
Programming the 3102 and 3105 using HART
Note
 Fast Key sequence 2, 2, 7 [or 8], 4 indicates the status Power Control Is Active (OFF/ON)
and the live Transmit Power level
Rosemount 3490 Series Control Unit
To enable or disable the transmit power
control
1. From the Main Menu screen, select SETUP.
2. Select the transmitter (e.g. “Tx1: 3102”).
3. Select ENGINEERING, and then select ADVANCED.
4. Select Tx Pwr Control.
5. Follow the on-screen instructions to edit and save the new setting.
(Use the Enter ( ) key if prompted to change mode to “off-line”).
6. Select “Quit” to exit to the previous menu.
F.3.33 Pulse repeat (P041)
The nominal rate of repetition for ultrasonic pulses from the transmitter is one pulse per second.
If two transmitters were located within the same tank, it is possible this would allow ultrasonic
pulses from one unit to be received by the other. This can be prevented by having both
transmitters operate with different rates of pulse repetition, which means this interference is
rejected as not consistent (pulse-to-pulse). Pulse Repeat allows the pulse repetition interval to
be adjusted by increments of 0.1 seconds.
This parameter is not available in the 3100 Series DD (Device Descriptor) file. However, it can be
adjusted using the integral buttons (see "Setting the pulse repetition frequency (on the 3102/3105)"
on page 67).
Rosemount 3490 Series Control Unit
To view or change the pulse rate
1. From the Main Menu screen, select SETUP.
2. Select the transmitter (e.g. “Tx1: 3102”).
3. Select ENGINEERING, and then select ADVANCED.
4. Select Pulse Repeat.
5. Follow the on-screen instructions to edit and save the new setting.
(Use the Enter ( ) key if prompted to change mode to “off-line”).
6. Select “Quit” to exit to the previous menu.
Fast Keys
–
Tx Pwr Control P040
Enable
Esc=Quit =Edit
(Rosemount 3491 Screen Shown)
Pulse Repeat P041
Standard(1.0s)
Esc=Quit =Edit
(Rosemount 3491 Screen Shown)
