Emerson Rosemount 3100 Series Reference Manual

210
Reference Manual
00809-0100-4840, Rev CB
Appendix F: Programming the 3102 and 3105 using HART
February 2015
Programming the 3102 and 3105 using HART
F.4.17 Model code (D949)
This indicates the transmitter model code.
Field Communicator or AMS Device
Manager
To view the transmitter model code
1. From the Home screen, select 1: Overview.
2. Select 3: Shortcuts.
3. Select 1: Device Information twice.
4. Select 1: Identification.
5. Select 2: Model Code D949.
6. When finished, select EXIT to exit to the previous menu.
Note
This is also at the Fast Key sequence 2, 2, 4 [or 5], 1, 5
(see Appendix E: Field Communicator Menus for a menu tree diagram).
Rosemount 3490 Series Control Unit
To view the transmitter model code
1. From the Main Menu screen, select SETUP.
2. Select the transmitter (e.g. “Tx1: 3102”).
3. Select SYSTEM.
4. Select FIXED.
5. Select HART.
6. Select Model Code.
7. When finished, use the ESC key to exit to the previous menu.
Fast Keys
1, 3, 1, 1, 1, 2
Model Code D949
3102
EXIT
HELP
(Field Communicator Screen Shown)
Model Code D949
3102
(Rosemount 3491 Screen Shown)
