136
Reference Manual
00809-0100-4840, Rev CB
Appendix F: Programming the 3102 and 3105 using HART
February 2015
Programming the 3102 and 3105 using HART
F.3.6 Bottom reference (P010)
This is the transmitter’s Bottom Reference setting. It is the distance measured vertically along
the ultrasonic beam path from the user preferred sensor reference point to the zero level of a tank
or an open channel (see Figure F-1 on page 137). It is not necessary to have the 4 mA output
start at the zero level, and the 4 mA starting pointing can be any liquid height above or below
this zero level.
Note
This parameter is important for calibrating and configuring the transmitter.
Field Communicator or AMS Device
Manager
To view or change the bottom reference
1. From the Home screen, select 2: Configure.
2. Select 2: Manual Setup.
3. Select 1: Basic Setup.
4. Select 2: Bottom Reference P010.
5. If a change is required:
(a) Input the new bottom reference, and then select “ENTER” to save it.
(b) Select “Send” or “Apply” to update the transmitter.
Rosemount 3490 Series Control Unit
To view or change the bottom reference
1. From the Main Menu screen, select SETUP.
2. Select the transmitter (e.g. “Tx1: 3102”).
3. Select DUTY.
4. Select Bottom Ref.
5. Follow the on-screen instructions to input and save the new setting. (Use the Enter ( )
key if prompted to change mode to “off-line”).
6. Select “Quit” to exit to the previous menu.
Fast Keys
2, 2, 1, 2
Bottom Reference P010
36.000 ft
36.000 ft
ESC
DEL ENTER
HELP
w
s
q
a
z
Lock
Shift
@ &
á ü
x
e
d
c
r
f
v
t
g
b
y
h
n
u
j
m
*
-
+
/
.
0
7
4
1
8
5
2
9
6
3
i
k
o
l
FN
(Field Communicator Screen Shown)
Bottom Ref. P010
36.000ft
Esc=Quit =Edit
(Rosemount 3491 Screen Shown)
