Appendix F: Programming the 3102 and 3105 using HART
February 2015
Programming the 3102 and 3105 using HART
F.4.4 Temperature / fourth variable (FV) (D903)
This indicates the live ambient temperature measured by the transmitter.
In HART terminology, this parameter is the Fourth Variable (FV). Measurement units are in C or
F depending on Base Units (page 118)
Field Communicator or AMS Device Manager
To view the live temperature
measurement
1. From the Home screen, select 3: Service Tools.
2. Select 2: Variables.
3. Select 1: Variables.
4. Select 4: Transducer Temperature D903.
5. When finished, select EXIT to exit to the previous menu.
Rosemount 3490 Series Control Unit
To view the live temperature
measurement
1. From the Main Menu screen, select MONITOR.
2. Select the transmitter (e.g. “Tx1: 3102”).
3. Select READINGS.
4. Select VARIABLES.
5. Select Xducer temp.
6. When finished, use the ESC key to exit to the previous menu.
Fast Keys
3, 2, 1, 4
Transducer Temperature D903
71.133 degF
EXIT
HELP
(Field Communicator Screen Shown)
Xducer Temp D903
67.9 F
(Rosemount 3491 Screen Shown)
