108 Functional description CG Drives & Automation 01-7492-01r1
Comm & I/O [254]
Communication Error [2541]
Delay time starts counting when the fault is gone. When the
time delay has elapsed, the alarm will be reset if the function
is active.
Communication Error Trip Type [2542]
Select the preferred way to react to a communication trip.
AnIn<Offset [2543]
Delay time starts counting when the fault is gone. When the
time delay has elapsed, the alarm will be reset if the function
is active.
AnIn Trip type [2544]
Select the preferred way to react to an AnIn<Offset alarm
trip.
Load monitor [255]
Min Alarm [2551]
Delay time starts counting when the fault is gone. When the
time delay has elapsed, the alarm will be reset if the function
is active.
Min Alarm Trip Type [2552]
Select the preferred way to react to a min alarm trip.
Max Alarm [2553]
Delay time starts counting when the fault is gone. When the
time delay has elapsed, the alarm will be reset if the function
is active.
Max Alarm Trip Type [2554]
Select the preferred way to react to a max alarm trip.
Pump [256]
Pump [2561]
Delay time starts counting when the fault is gone. When the
time delay has elapsed, the alarm will be reset if the function
is active.
2541 Com Error
Default: Off
Range: Off, 1–3600 s (Off=0)
2542 Com ErrorTT
Default: Trip
Trip 0 The motor will coast
Decele-
ration
1 The motor will decelerate
2543 AnIn<Offset
Default: Off
Range: Off, 1–3600 s (Off=0)
2544 AnIn TT
Default: Trip
Trip 0 The motor will coast
Decele-
ration
1 The motor will decelerate
2551 Min Alarm
Default: Off
Range: Off, 1–3600 s (Off=0)
2552 Min AlarmTT
Default: Trip
Trip 0 The motor will coast
Decele-
ration
1 The motor will decelerate
2553 Max Alarm
Default: Off
Range: Off, 1–3600 s (Off=0)
2554 Max AlarmTT
Default: Trip
Trip 0 The motor will coast
Decele-
ration
1 The motor will decelerate
2561 Pump
Default: Off
Range: Off, 1–3600 s (Off=0)
