CG Drives & Automation 01-7492-01r1 153
AnIn1 Bipol [5133]
This menu is only displayed if AnIn1 Setup is set to User
Bipol mA or User Bipol V. The window will
automatically show mA or V range according to selected
function. The range is set by changing the positive
maximum value; the negative value is automatically adapted
accordingly. The inputs RunR and RunL input need to be
active, and “Rotation [219]”, must be set to “R+L”, to
operate the bipolar function on the analogue input.
AnIn1 Function Min [5134]
With AnIn1 Function Min the physical minimum value is
scaled to selected process unit. The default scaling is
dependent of the selected function of AnIn1 [511].
Table 36 shows corresponding values for the min and max
selections depending on the function of the analogue input
[511].
AnIn1 Function Value Min [5135]
With AnIn1 Function ValMin you define a user-defined
value for the signal. Only visible when user-defined is
selected in menu [5134].
AnIn1 Function Max [5136]
With AnIn1 Function Max the physical maximum value is
scaled to selected process unit. The default scaling is
dependent of the selected function of AnIn1 [511]. See table
36.
AnIn1 Function Value Max [5137]
With AnIn1 Function VaMax you define a user-defined
value for the signal. Only visible when user-defined is
selected in menu [5136].
Example:
Process sensor is a sensor with the following specification:
Range: 0–3 bar
Output: 2–10 mA
Analogue input should be set up according to:
[512] AnIn1 Setup = User mA
[5131] AnIn1 Min = 2 mA
[5132] AnIn1 Max = 10 mA
[5134] AnIn1 Function Min = User-defined
[5135] AnIn1 VaMin = 0.000 bar
[5136] AnIn 1 Function Max = User-defined
[5137] AnIn1 VaMax = 3.000 bar
AnIn1 Operation [5138]
5133 AnIn1 Bipol
Default: 10.00 V/20.00 mA
Range: 0.0–20.0 mA, 0.00–10.00 V
5134 AnIn1 FcMin
Default: Min
Min 0 Min value
Max 1 Max value
User
defined
2 Define user value in menu [5135]
Ta b l e 3 6
AnIn Function Min Max
Speed Min Speed [341] Max Speed [343]
Torque 0% Max Torque [351]
Process Ref Process Min [324] Process Max [325]
Process Value Process Min [324] Process Max [325]
5135 AnIn1 VaMin
Default: 0.000
Range: -10000.000 – 10000.000
5136 AnIn1 FcMax
Default: Max
Min 0 Min value
Max 1 Max value
User
defined
2 Define user value in menu [5137]
5137 AnIn1 VaMax
Default: 0.000
Range: -10000.000 – 10000.000
NOTE: With AnIn Min, AnIn Max, AnIn Function Min
and AnIn Function Max settings, loss of feedback
signals (e.g. voltage drop due to long sensor wiring)
can be compensated to ensure an accurate process
control.
5138 AnIn1 Oper
Default: Add+
Add+ 0
Analogue signal is added to selected
function in menu
[511].
Sub- 1
Analogue signal is subtracted from
selected function in menu
[511].
