184 CG Drives & Automation 01-7492-01r1
* Warning messages ExtTrip1 - ExtTrip4 are configurable in
menu [430].
See also chapter 12. page 193.
Digital Input Status [723]
Indicates the status of the digital inputs. See fig. 143.
1DigIn 1
2DigIn 2
3DigIn 3
4DigIn 4
5DigIn 5
6DigIn 6
7DigIn 7
8DigIn 8
The positions one to eight (read from left to right) indicate
the status of the associated input:
1High
0Low
The example in fig. 143 indicates that DigIn 1,
DigIn 3 and DigIn 6 are active at this moment.
Fig. 143 Digital input status example
Digital Output Status [724]
Indicates the status of the digital outputs and relays. See fig.
144.
RE indicate the status of the relays on position:
1Relay1
2Relay2
3Relay3
DO indicate the status of the digital outputs on position:
1DigOut1
2DigOut2
The status of the associated output is shown.
1High
0Low
The example in fig. 144 indicates that DigOut1 is active and
Digital Out 2 is not active. Relay 1 is active, relay 2 and 3
are not active.
Fig. 144 Digital output status example
Communication
integer value
Warning message
0No Error
1 Motor I
²
t
2PTC
3 Motor lost
4 Locked rotor
5ExtTrip1*
6Mon MaxAlarm
7Mon MinAlarm
8Comm error
9 PT100
10 Crane Deviat
11 Pump
12 Ext Mot Temp
13 LC Level
14 Brake
15 Option
16 Over temp
17 Over curr F
18 Over volt D
19 Over volt G
20 Over volt
21 Over speed
22 Under voltage
23 Power fault
24 Desat
25 DClink error
26 Int error
27 Ovolt m cut
28 Over voltage
29 STO Active
30 Crane Comm
31 Encoder
32 ExtTrip2*
33 AnIn<Offset
34 ExtTrip3*
35 ExtTrip4*
723 0rpm
DigIn Status
10100100
Sby Rem/Rem
724 0rpm
DigOutStatus
RE 100 DO 10
Sby Rem/Rem
