CG Drives & Automation 01-7492-01r1 Functional description 91
Run/Stop Control [215]
This function is used to select the source for run and stop
commands. This is described on page 128.
Start/stop via analogue signals can be achieved by using
function “Stp<MinSpd [342]”.
Reset Control [216]
When the AC drive is stopped due to a failure, a reset
command is required to make it possible to restart the AC
drive. Use this function to select the source of the reset
signal.
Local/Remote key function [217]
The Toggle key on the keyboard, see section 10.2.8, page
83, has two functions and is activated in this menu. As
default the key is just set to operate as a Toggle key that
moves you easily through the menus in the toggle loop. The
second function of the key allows you to easily swap between
Local and normal operation (set up via [214] and [215]) of
the AC drive. Local mode can also be activated via a digital
input. If both [2171] and [2172] is set to Standard, the
function is disabled.
Lock Code? [218]
To prevent the keyboard being used or to change the setup
of the AC drive and/or process control, the keyboard can be
locked with a password. This menu, “Lock Code [218]”, is
used to lock and unlock the keyboard. Enter the password
“291” to lock/unlock the keyboard operation. If the
keyboard is not locked (default) the selection “Lock Code?”
will appear. If the keyboard is already locked, the selection
“Unlock Code?” will appear.
When the keyboard is locked, parameters can be viewed but
not changed. The reference value can be changed and the
AC drive can be started, stopped and reversed if these
functions are set to be controlled from the keyboard.
215 Run/Stp Ctrl
Default: Remote
Remote 0
The start/stop signal comes from the digital
inputs of the terminal strip (terminals 1-22).
For settings, see menu group [330] and
[520].
Keyboard 1 Start and stop is set on the Control Panel.
Com 2
The start/stop is set via
communication, i.e. via RS485, Fieldbus,
or wireless interface. See Fieldbus or RS-
232/485 option manual for details and
chapter 9.4 Start and stop commands
page 76.
Option 3 The start/stop is set via an option.
216 Reset Ctrl
Default: Remote+Keyb
Remote 0
The command comes from the inputs of
the terminal strip (terminals 1-22).
Keyboard 1
The command comes from the
command keys of the Control Panel.
Com 2
The command comes from
communication (RS485, Fieldbus,
wireless).
Remote +
Keyb
3
The command comes from the inputs of
the terminal strip (terminals 1-22) or the
keyboard.
Com +
Keyb
4
The command comes from
communication (RS485, Fieldbus,
wireless) or the keyboard.
Rem+Keyb
+Com
5
The command comes from the inputs of
the terminal strip (terminals 1-22), the
keyboard or communication (RS485,
Fieldbus, wireless).
Option 6
The command comes from an option.
Only available if the option can control
the reset command.
2171 LocRefCtrl
Default: Standard
Standard 0 Local reference control set via [214]
Remote 1 Local reference control via remote
Keyboard 2 Local reference control via keyboard
Com 3 Local reference control via communication
2172 LocRunCtrl
Default: Standard
Standard 0 Local Run/Stop control set via [215]
Remote 1 Local Run/Stop control via remote
Keyboard 2 Local Run/Stop control via keyboard
Com 3
Local Run/Stop control via
communication
218 Lock code?
Default: 0
Range: 0–9999
