Commissioning Proline Promass E 300 PROFINET
108 Endress+Hauser
Configuring the switch output
Navigation
"Setup" menu → Pulse/frequency/switch output
‣
Pulse/frequency/switch output
1 to n
Operating mode
→  108
Terminal number
→  108
Signal mode
→  108
Switch output function
→  109
Assign diagnostic behavior
→  109
Assign limit
→  110
Assign flow direction check
→  110
Assign status
→  111
Switch-on value
→  111
Switch-off value
→  111
Switch-on delay
→  111
Switch-off delay
→  111
Failure mode
→  111
Invert output signal
→  111
Parameter overview with brief description
Parameter Prerequisite Description Selection / User
interface / User
entry
Factory setting
Operating mode – Define the output as a pulse,
frequency or switch output.
• Pulse
• Frequency
• Switch
–
Terminal number – Shows the terminal numbers
used by the PFS output
module.
• Not used
• 24-25 (I/O 2)
• 22-23 (I/O 3)
–
Signal mode – Select the signal mode for the
PFS output.
• Passive
• Active
• Passive NAMUR
–
