Enterasys SSA-G1018-0652 - SSA-T1068-0652 Front Panel; SSA-G1018-0652 Front Panel

SSA-T1068-0652
1-2 Introduction
SSA-T1068-0652
TheSSA‐T1068‐0652hasforty‐eight10/100/1000BASE‐TRJ45portsandfour10GBASE‐XSFP+
ports,asshowninFigure 1‐2.
Figure 1-2 SSA-T1068-0652 Front Panel
Eachofthe10/100/1000BASE‐Tports,whichsupportPoE(IEEE802.3afand802.3a t),canoperate
ineitherhalf‐duplexorfull‐duplexmodewhichcanbedeterminedby
eitherauto‐negotiationor
manualconfiguration.TheSSA‐T1068‐0652canprovidePoEpowerforpowereddevicesonall48
RJ45portssimultaneously.
TheSFP+portssupportanumberofSFP+pluggabletransceivers.Formoreinformationaboutthe
transceivers,seethefollowing:
http://www.enterasys.com/products/transceivers‐ds.pdf
SSA-G1018-0652
TheSSA‐G1018‐0652hasforty‐eight1000BASE‐TSFPportsandfour10GBASE‐XSFP+ports,as
showninFigure 1‐3.
Figure 1-3 SSA-G1018-0652 Front Panel
Eachofthe1000BASE‐Tportscanoperateineitherhalf‐duplexorfull‐duplexmodewhichcanbe
determinedbyeitherauto‐negotiationormanualconfiguration.
The
SFPandSFP+portssupportanumberofSFPandSFP+pluggabletransceivers.Formore
informationaboutthetransceivers,seethefollowing:
http://www.enterasys.com/products/transceivers‐ds.pdf
1 10/100/1000BASE-T RJ45 ports 5 Micro-USB debug port
2 10GBASE-X SFP+ ports 6 OFFLINE/RESTART button
3 PoE mode button 7 COM port
4 System LEDs
1 1000BASE-T SFP ports 4 Micro-USB debug port
2 10GBASE-X SFP+ ports 5 OFFLINE/RESTART button
3 System LEDs 6 COM port
