Pluggable Transceiver Specifications
A-2 Specifications
Pluggable Transceiver Specifications
ForSFPandSFP+transceiverspecifications,refertothedatasheetatthefollowingURL:
http://www.enterasys.com/products/transceivers‐ds.pdf
COM Port Pinout Assignments
TheCOMportisanRJ45communicationsportforlocalaccesstolocalmanagement.Refertothe
tablebelowfortheCOMportpinassignments.
SSA-AC-PS-1000W
Input Frequency 50 to 60 Hz
Input (Voltage/Current) at Output Power 100 to 125 Vac: 12 A at 1000 watts
200 to 240 Vac: 7 A at 1200 watts
Approximate Weight 1.22 kg (3.1 lb)
SSA-AC-PS-625W
Input Frequency 50 to 60 Hz
Input (Voltage/Current) at Output Power 100 to 240 Vac: 8 A at 625 watts
Approximate Weight 1.41 kg (2.7 lb)
Environmental
Operating Temperature 5°C to 40°C (41°F to 104°F)
Storage Temperature -30°C to 73°C (-22°F to 164°F)
Operating Relative Humidity 5% to 95% (non-condensing)
Table A-1 Specifications (continued)
Item Specification
Table A-2 COM Port Pin Assignments
Pin Signal Name Input/Output
1 Transmit Data (XMT) Output
2 Data Carrier Detect (DCD) Output
3 Data Set Ready (DSR) Input
4 Receive Data (RCV) Input
5 Signal Ground (GND) NA
6 Data Terminal Ready (DTR) Output
7 Request to Send (RTS) Input
8 Clear to Send (CTS) NA
