Mounting the SSA
2-10 Installation
Rack Mounting the SSA in a Two-post Rack (3-inch Posts)
Inatwopostrackwith3inchposts,threemidmountpositionsarepossible.SeeFigure 26for
possiblemountingpositions,asshownontherightpost.EnterasysNetworksconsidersthetop
midmountpositionshowninFigure 26tobethebestofthethreeoptions.
Figure 2-6 Installation Positions in a Two-post Rack (3-inch Posts)
Torack
mounttheSSAinatwopostrackwith3inchposts:
1. Removetheextensionsfromeachrackrailbyunscrewingtherailclamps.SeeFigure 23on
page 27.
TherailextensionsandrailclampsarenotusedtoinstallanSSAinatwopostrack.
2. Usingtheeight6
32screwsremovedinstep1,attachthemountingbrackettoeachrail(four
screwsforeachmountingbracket)intheappropriateorientationforthemountingoptionthat
youhavechosen.SeeFigure 26.
3. Securethemountingbracketstotherackpostswiththreecustomersuppliedscrewsineach
mounting
bracket.
Dependingonthemountingoption,youmustsecurethemountingbracketstoeitherthefront
orbackoftherackposts.SeeFigure 26.
Note: If you plan to secure the rear of the SSA to the rails, you must remove the screw in the left
rear corner of the SSA BEFORE you install the SSA in the rack. For more information, see
Securing the SSA to the Rear of the Rails” on page 2-11.
The SSA rail kit does not include screws for attaching the mounting brackets to the rack posts.
Caution: If you are installing an SSA in a four-post or two-post rack, you must use the SSA rail kit to
install the SSA in the rack. Do not attempt to secure the SSA directly to the rack using the small
front mounting ears.
Precaución: Si instala un SSA en un estante de cuatro o de dos postes, debe usar el kit de rieles
de SSA para realizar la instalación. No intente asegurar el SSA directamente en el estante usando
las lengüetas de montaje delanteras pequeñas.
