Enterasys S-Series Stand Alone (SSA) Hardware Installation Guide 3-1
3
Troubleshooting
Thischapterprovidesinformationconcerningthefollowing:
LEDs
TheSSAhasport,system,andpowersupplyLEDs.
Port LEDs
OntheSSA,youcanviewthereceiveandtransmitactivityontheRXandTXLEDsfortheRJ45,
SFP,andSFP+ports.SeeFigure 3‐1andFigure 3‐2.
Figure 3-1 RJ45 Port LEDs
For information about... Refer to page...
LEDs 3-1
Troubleshooting Checklist 3-5
Replacing the SSA Fans 3-7
Using the OFFLINE/RESET Button 3-17
1 RX LED 2 TX LED
