Section 10: Material Engraving Techniques

112

RUBBER STAMP CORRECT SETUP USING COMBINED MODE

CORRECT EXAMPLE #1

CORRECT EXAMPLE #2

CORRECT EXAMPLE #3

RUBBER STAMP INCORRECT SETUP USING COMBINED MODE

Use only one fence to surround

all stamps on the page.
