Section 10: Material Engraving Techniques

113

INCORRECT EXAMPLE #1

INCORRECT EXAMPLE #2

After you have successfully setup your artwork, print your design by selecting

FILE/PRINT. Choose the Epilog Driver printer. Next click on the PROPERTIES

button and the following print driver window will appear.
