Epson AcuLaser C2800 - Duplex

AcuLaser C2800/C2800D/C3800/C3800D Revision C
DISASSEMBLY/REASSEMBLY Disassembly/Reassembly 349
Confidential
4.4.22 DUPLEX
DISASSEMBLED PARTS
LOCATION
Table 4-21. List of Disassembled Parts
Name Guide
FEEDER ASSY DUP
COVER PWBA DUP
ACTUATOR DUP
SENSOR PHOTO: DUP, JAM
PWBA DUP-H
CLUTCH DUP
ROLL ASSY DUP-1
FAN DUP
ROLL ASSY DUP-2
MOTOR ASSY DUP
A
B
C
D
E
FEEDER ASSY DUP
COVER PWBA DUP
FAN DUP
ROLL ASSY DUP-2
MOTOR ASSY DUP
