AcuLaser C2800/C2800D/C3800/C3800D Revision C
DISASSEMBLY/REASSEMBLY Disassembly/Reassembly 217
Confidential
4.4.7 PAPER CASSETTE (PART 2)
DISASSEMBLED PARTS
LOCATION
Table 4-6. List of Disassembled Parts
Name Guide
ACTUATOR NO PAPER MSI
KIT ROLL ASSY FEED SEC (RETARD)
HANDLE CST
COVER FRONT MSI
A
B
C
HANDLE CST
KIT ROLL ASSY FEED SEC (RETARD)
ACTUATOR NO PAPER MSI COVER FRONT MSI
To Next Page
