Epson AcuLaser C2800 User Manual

AcuLaser C2800/C2800D/C3800/C3800D Revision C
DISASSEMBLY/REASSEMBLY Disassembly/Reassembly 337
Confidential
4.4.20 ELECTRICAL (PART 2)
DISASSEMBLED PARTS
LOCATION
Table 4-19. List of Disassembled Parts
Name Guide
PWBA EEPROM XPRO
PWBA USB
SWITCH POWER
BOARD ASSY, MAIN
A
B
C
D
PWBA EEPROM XPRO
BOARD ASSY, MAIN
PWBA USB
SWITCH POWER
