2.9 Features of the Controller
MAIN FEATURES
 A4 color tandem engine
 Print speed: 25 ppm (Monochrome)/20 ppm (Color)
 Resolution: 600 dpi/1200 dpi (Print speed is reduced by half at 1200 dpi)
 Clock frequency: 133.3 MHz
 Program ROM DIMM: 16 MB (standard), Flash ROM DIMM: C533PROG (option)
 Processing language: ESC/PAGE-Color, PostScript3, PCL5c, PCL6c (standard)
 Optional ROM DIMM that supports Chinese and Unicode fonts
 LCD wide panel (with back light)
OUTLINE SPECIFICATIONS
The following table shows the outline specifications of the controller.
Table 2-3. Controller Outline Specifications
Item Description
Engine specifications A4 color tandem
Print speed Color: 20 ppm
B/W: 25 ppm
CPU
 AcuLaser C2800/C2800D
PowerPC 750FL-400
 AcuLaser C3800/C3800D
PowerPC 750FL-600
ASIC Memory ASIC
Video ASIC
FMV + PLD
I/O ASIC FAIO
Panel PCC
Clock Clock driver HD151TS311
Clock frequency 133.3 MHz
Reset M51957BFP
ROM Connector specification 90pin DIMM
Device capacity C533PROG, FLASH 16MB
Extended ROM slot 1 slot
Optional ROM Chinese, Unicode fonts
SDRAM DDR333
Standard SDRAM 200pin SO DIMM 128 MB
SDRAM slot 2 slot
Max. SDRAM capacity
 AcuLaser C2800/C2800D : 640MB
 AcuLaser C3800/C3800D : 1GB
PWM SP4NX-C (E05C031A)
Control panel Wide panel
Buttons x 6
LED x 3
with back light
USB USB2.0 HS
Type-B Installed
Network standard 100BaseTX/10BaseT
USB host Specification USB 1.1 integrated host
(AcuLaser C3800/C3800D only)
Device SIR720005
Clock 12.0000 MHz
