Epson AcuLaser C2800 - Abnormal Noise-Related FIP

AcuLaser C2800/C2800D/C3800/C3800D Revision C
TROUBLESHOOTING Abnormal Noise-related Trouble 152
Confidential
3.6.2 Abnormal Noise-related FIP
FIP-N1 AT POWER ON
 Possible parts that caused the error
 Troubleshooting
FIP-N2 DURING STANDBY
 Possible parts that caused the error
 Troubleshooting
 DRIVE ASSY MAIN
 FUSER UNIT
 IMAGING CARTRIDGE (Y/M/C/K)
 TRANSFER UNIT
 FEEDER ASSY DUP
Step Check Yes No
1
Is abnormal noise being
generated by the DRIVE ASSY
MAIN?
Reinstall the DRIVE
ASSY MAIN. When the
trouble still occurs,
replace the DRIVE
ASSY MAIN. (p.317)
Go to Step [2].
2
Is abnormal noise being
generated by the FUSER UNIT?
Reinstall the FUSER
UNIT.
When the trouble still
occurs, replace the
FUSER UNIT. (p.298)
Go to Step [3].
3
Is abnormal noise being
generated by the IMAGING
CARTRIDGE (Y/M/C/K)?
Reinstall the IMAGING
CARTRIDGE (Y/M/C/
K). When the trouble still
occurs, replace the
IMAGING
CARTRIDGE (Y/M/C/
K). (p.271)
Go to Step [4].
Step Check Yes No
4
Is abnormal noise being
generated by the TRANSFER
UNIT?
Reinstall the
TRANSFER UNIT.
When the trouble still
occurs, replace the
TRANSFER UNIT.
(p.268)
Go to Step [5].
5
Is abnormal noise being
generated by the FEEDER ASSY
DUP?
Reinstall the FEEDER
ASSY DUP. When the
trouble still occurs,
replace the FEEDER
ASSY DUP. (p.349)
---
 FAN MAIN  LVPS
Step Check Yes No
1
Is abnormal noise being
generated by the FAN MAIN?
Reinstall the FAN
MAIN. When the trouble
still occurs, replace the
FAN MAIN. (p.327)
Go to Step [2].
2
Is abnormal noise being
generated by the LVPS?
Replace the LVPS.
(p.327)
---
