EPSON AcuLaser C2800/C2800D/C3800/C3800D Revision C
APPENDIX Information Sheets 416
Confidential
Note : If you cannot find the corresponding code in the table, multiple paper jam may be
occurring. In that case, convert the displayed code (hexadecimal number) into binary
number and find the combination in the table.
e.g.) 00002080 (hexadecimal number) → 00100000 10000000 (binary number)
→ 00100000 00000000 + 00000000 10000000 → Duplex Jam 3 + Reg Jam 1
Table 7-4. Paper Jam Code
Hexadecimal number
(Engine status indication)
Bit Binary number Description
00040000 18 100 00000000 00000000 Remain at Dup
00020000 17 10 00000000 00000000 Remain at Exit
00010000 16 1 00000000 00000000 Remain at Reg
00008000 15 10000000 00000000 ---
00004000 14 1000000 00000000 Duplex Jam 4
00002000 13 100000 00000000 Duplex Jam 3
00001000 12 10000 00000000 Duplex Jam 2
00000800 11 1000 00000000 Duplex Jam 1
00000400 10 100 00000000 Exit Jam 2
00000200 9 10 00000000 Exit Jam 1
00000100 8 1 00000000 Reg Jam 2
00000080 7 10000000 Reg Jam 1
00000040 6 1000000 Feed Jam
00000020 5 100000 ---
00000010 4 10000 ---
00000008 3 1000 Tray2 Misfeed Jam
00000004 2 100 Tray1 Misfeed Jam
00000002 1 10 MSI Misfeed Jam
00000001 0 1 ---
