Epson AcuLaser C2800 User Manual

Confidential
 Safety System Wiring Schematic
LVPSHARNESS
ASSY INLET
SWITCH POWER
FUSER ASSY
PWBA MCU
DC Power Supply
AC H AC N
Heater
Control
Heater ON
AC H
AC H
HARNESS ASSY INTERLOCK
Fuser
Control
+24VDC
DRIVE ASSY PH CLUTCH ASSY PH REGI DRIVE ASSY MAIN SOLENOID FEED MSI ROS ASSY CLUTCH ASSY PH TURN CLUTCH ASSY PH FEED TRANSFER ASSY DISPENSER ASSY (Y)/(M)/(C)/(K) HVPS
+5VDC
+3.3VDC
CLUTCH ASSY PH TURN CLUTCH ASSY PH FEED DRIVE ASSY OPT FDR
PWBA OPT FDR PWBA DUP
CLUTCH ASSY DUP MOTOR ASSY DUP
I/L +24V
I/L +24V
I/L +24V I/L +24V
I/L +24V
I/L +24V I/L +24V
I/L +24V
I/L +24V I/L +24V
I/L +24V I/L +24V I/L +24V I/L +24V I/L +24V
Kmy00013EB
+5VDC
+3.3VDC
+5VDC +5VDC
+3.3VDC +3.3VDC
PWBA ESS
Heater
Thermostat
Thermister
+24VDC
