Epson DiscProducer PP-100N User Manual

143
Maintenance
Replacing the ink pad
The ink pad is a part that absorbs waste ink ejected during head cleaning or printing. When it becomes time to replace
the ink pad, publishing becomes no longer possible.
How to check when it is time to replace the ink pad
You can replace the ink pad in one of the following two ways.
• In EPSON Total Disc Monitor, a message says “It is almost time to replace the ink pad. Early replacement is
recommended. For information on replacement, please contact customer support.“ The message is displayed once
per day when EPSON Total Disc Monitor starts up. See “EPSON Total Disc Monitor” on page 50 in this guide for
EPSON Total Disc Monitor.
• A message notifying you that it is almost time to replace the ink pad is displayed on the LCD.
When it is time to replace the ink pad, disc publishing stops, and a message notifying you that it is time to replace the
ink pad is displayed on the LCD. The ink pad cannot be replaced by the customer. Please contact Customer Support.
If an administrator has set notification email transmission, an email is sent to notify each
administrator that the ink pad needs to be replaced soon or the ink pad needs to be
replaced.
Note
s

Epson DiscProducer PP-100N Specifications

General

Capacity	50 discs
Interface	Ethernet
Product color	Black, Grey
Printing colors	Black, Cyan, Light cyan, Light magenta, Magenta, Yellow
Country of origin	China
Quantity per pack	1 pc(s)
Media types supported	CD-R, DVD-R, DVD+R, DVD-R DL, DVD+R DL
Optical disc diameter	120 mm
Publishing speed (CD)	30 discs/hour
Publishing speed (DVD)	17 discs/hour
Number of CD/DVD drives	2
Compatible operating systems	Windows 7, Windows 8 (32/64 bit), Windows Server 2003 (32/64bit), Windows Server 2008 (32/64bit), Windows Server 2012 (64bit), Windows Vista, Windows XP
Print speed (speed mode)	60 discs/hour
Print speed (quality mode)	42 discs/hour
Print resolution (speed mode)	1440 x 1440 DPI
Print resolution (quality mode)	1440 x 720 DPI
CD write speed	40 x
DVD-R write speed	12 x
Ethernet LAN (RJ-45) ports	1
Ethernet LAN	Yes
Pallet width	800 mm
Pallet height	1011 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	6 pc(s)
Quantity per pallet layer	2 pc(s)

Weight and Dimensions

Package depth	725 mm
Package height	525 mm
Package weight	29200 g
Dimensions (WxDxH)	730 x 530 x 522 mm
