Epson DiscProducer PP-100N User Manual

19
Part Names and Functions
Unlocking the disc cover
If the security lock switch is set to on, the disc cover is locked automatically each time it is closed. To unlock the disc
cover lock, use the disc cover key or use the control panel.
Unlocking the lock using the disc cover key
Insert the disc cover key into the disc cover lock, and turn it to the [UNLOCK] position.
Unlocking the lock using the control panel
1
Press the MENU button.
The disc cover unlock screen appears.
2
Press the button.
When the disc cover lock is unlocked, “Disc cover can be opened” appears on the LCD.
If the security lock switch is set to off, the disc cover lock always remains unlocked.
If the disc cover is not opened within 5 seconds after the lock is unlocked, the disc cover is
locked again.
Note
s
Top menu
Cover unlocked
Note
s

Epson DiscProducer PP-100N Specifications

General

Capacity	50 discs
Interface	Ethernet
Product color	Black, Grey
Printing colors	Black, Cyan, Light cyan, Light magenta, Magenta, Yellow
Country of origin	China
Quantity per pack	1 pc(s)
Media types supported	CD-R, DVD-R, DVD+R, DVD-R DL, DVD+R DL
Optical disc diameter	120 mm
Publishing speed (CD)	30 discs/hour
Publishing speed (DVD)	17 discs/hour
Number of CD/DVD drives	2
Compatible operating systems	Windows 7, Windows 8 (32/64 bit), Windows Server 2003 (32/64bit), Windows Server 2008 (32/64bit), Windows Server 2012 (64bit), Windows Vista, Windows XP
Print speed (speed mode)	60 discs/hour
Print speed (quality mode)	42 discs/hour
Print resolution (speed mode)	1440 x 1440 DPI
Print resolution (quality mode)	1440 x 720 DPI
CD write speed	40 x
DVD-R write speed	12 x
Ethernet LAN (RJ-45) ports	1
Ethernet LAN	Yes
Pallet width	800 mm
Pallet height	1011 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	6 pc(s)
Quantity per pallet layer	2 pc(s)

Weight and Dimensions

Package depth	725 mm
Package height	525 mm
Package weight	29200 g
Dimensions (WxDxH)	730 x 530 x 522 mm
