77
Publishing Discs
Printable area
The printable area is the area of the label surface on which printing is possible.
The printable area and recommended print area are shown in the table below. Printing will be done in the gray area in
the figure below.
Set the print area in [Set Inside/Outside Diameter] of EPSON Total Disc Maker or [Label Size] on the printer driver
screen. Select from [Standard] and [Wide], or set an optional size. (See “Changing the print area” on page 78 in this
guide for how to set an optional size.)
The print areas of [Standard] and [Wide] are shown in the table below. Printing will be done in the gray area in the
figure below.
• Printing outside of the recommended print area may result in the discs or tray
becoming dirty, peeling off or blurring of the print, or discs sticking together.
• If you print outside of the printing range (ink absorbing layer) of the discs you are using,
the ink printed outside the printing area will not fix. Check the label print range of the
discs you are using before configuring the setting.
Printable area Recommended print area
Inside diameter Outside diameter Inside diameter Outside diameter
18.0 mm 119.4 mm 45.0 mm 116.0 mm
Standard Wide
Inside diameter Outside diameter Inside diameter Outside diameter
45.0 mm 116.0 mm 25.5 mm 116.0 mm
Inside Diameter
Outside Diameter
Inside Diameter
Outside Diameter
Inside Diameter
Outside Diameter
Inside Diameter
Outside Diameter
To Next Page
