Epson DiscProducer PP-100N User Manual

15
Part Names and Functions
Control panel
*
Job: Processing performed by this product, such as writing and printing data
1Power LED
Flashes and turns on when the power is turned on.
2BUSY LED
Flashes when a job
*
is being processed or a job is being received.
3 ERROR LED
Flashes and turns on when an error occurs.
4LCD
Shows menus and messages.
5 EJECT button
Do not use in Standard Mode, External Output Mode, and Batch Mode.
6 button
Confirms the selection and runs processing.
7 ▲/▼ buttons
Moves to different menus.
8 CANCEL button
Cancels the selection.
9 buttons
Moves the digit when you change the IP address.
10 MENU button
Displays the top menu.
2
3
1
4
5 6
7
8910
/

Epson DiscProducer PP-100N Specifications

General

Capacity	50 discs
Interface	Ethernet
Product color	Black, Grey
Printing colors	Black, Cyan, Light cyan, Light magenta, Magenta, Yellow
Country of origin	China
Quantity per pack	1 pc(s)
Media types supported	CD-R, DVD-R, DVD+R, DVD-R DL, DVD+R DL
Optical disc diameter	120 mm
Publishing speed (CD)	30 discs/hour
Publishing speed (DVD)	17 discs/hour
Number of CD/DVD drives	2
Compatible operating systems	Windows 7, Windows 8 (32/64 bit), Windows Server 2003 (32/64bit), Windows Server 2008 (32/64bit), Windows Server 2012 (64bit), Windows Vista, Windows XP
Print speed (speed mode)	60 discs/hour
Print speed (quality mode)	42 discs/hour
Print resolution (speed mode)	1440 x 1440 DPI
Print resolution (quality mode)	1440 x 720 DPI
CD write speed	40 x
DVD-R write speed	12 x
Ethernet LAN (RJ-45) ports	1
Ethernet LAN	Yes
Pallet width	800 mm
Pallet height	1011 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	6 pc(s)
Quantity per pallet layer	2 pc(s)

Weight and Dimensions

Package depth	725 mm
Package height	525 mm
Package weight	29200 g
Dimensions (WxDxH)	730 x 530 x 522 mm
