Epson DiscProducer PP-100N User Manual

83
Publishing Discs
Loading discs
This section describes how to load discs in the stacker, and insert the stacker.
1
Fully separate the discs to prevent them from sticking together.
2
Take out the input stacker and load the discs into it.
The stacker to use as the input stacker differs depending on the set Publish Mode. Confirm the input stacker in
the following table.
Load the discs in a stacker. Do not load discs in the drives or printer. Furthermore, do not
load discs between Drive 1 and Drive 2. They may become unable to be taken out.
• Be sufficiently careful not to scratch a disc.
• If a long time elapses after discs are loaded in the stacker, the separated discs may
stick together again. Fan the discs again if a long time has elapsed since they were
loaded.
Do not replenish or remove discs while the stacker is attached to this product. Be sure to
remove the stacker beforehand.
Publish Mode Input Stacker Number of Discs
Standard Mode Stacker 1 Up to approximately 50 discs
External Output Mode
(Different types of discs can be loaded into Stacker 1
and Stacker 2.)
Stacker 1 Up to approximately 50 discs
Stacker 2 Up to approximately 50 discs
Batch Mode Stacker 1 Up to approximately 50 discs
Stacker 2 Up to approximately 50 discs
Place the label surface facing upwards.

Epson DiscProducer PP-100N Specifications

General

Capacity	50 discs
Interface	Ethernet
Product color	Black, Grey
Printing colors	Black, Cyan, Light cyan, Light magenta, Magenta, Yellow
Country of origin	China
Quantity per pack	1 pc(s)
Media types supported	CD-R, DVD-R, DVD+R, DVD-R DL, DVD+R DL
Optical disc diameter	120 mm
Publishing speed (CD)	30 discs/hour
Publishing speed (DVD)	17 discs/hour
Number of CD/DVD drives	2
Compatible operating systems	Windows 7, Windows 8 (32/64 bit), Windows Server 2003 (32/64bit), Windows Server 2008 (32/64bit), Windows Server 2012 (64bit), Windows Vista, Windows XP
Print speed (speed mode)	60 discs/hour
Print speed (quality mode)	42 discs/hour
Print resolution (speed mode)	1440 x 1440 DPI
Print resolution (quality mode)	1440 x 720 DPI
CD write speed	40 x
DVD-R write speed	12 x
Ethernet LAN (RJ-45) ports	1
Ethernet LAN	Yes
Pallet width	800 mm
Pallet height	1011 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	6 pc(s)
Quantity per pallet layer	2 pc(s)

Weight and Dimensions

Package depth	725 mm
Package height	525 mm
Package weight	29200 g
Dimensions (WxDxH)	730 x 530 x 522 mm
