Epson DiscProducer PP-100N User Manual

42
Using Applications
EPSON Total Disc Maker
What is EPSON Total Disc Maker?
EPSON Total Disc Maker is software for editing the write data and the print data for the label surface, and publishing
to this product (PP-100N).
In EPSON Total Disc Maker, the execution of writing data to this product and printing labels is referred to as
“publishing”. Publishing enables this product to write data to a CD or DVD and print the label to create a finished
disc.
Starting EPSON Total Disc Maker
1
Select [Start] ( in Windows 7 or Windows Vista) - [All Programs] (or [Programs]) -
[EPSON Total Disc Maker] - [EPSON Total Disc Maker].
The [Open] dialog box appears.
2
Click [Cancel].
The [Open] dialog box closes and the disc view becomes active.
• If you select a Total Disc Maker data file in the [Open] dialog box and then click
[Open], the selected file opens and the publish view becomes active.
• If you unselect [Show this dialog box at startup] and close the [Open] dialog box, the
[Open] dialog box is not displayed from the next startup.
Note
s

Epson DiscProducer PP-100N Specifications

General

Capacity	50 discs
Interface	Ethernet
Product color	Black, Grey
Printing colors	Black, Cyan, Light cyan, Light magenta, Magenta, Yellow
Country of origin	China
Quantity per pack	1 pc(s)
Media types supported	CD-R, DVD-R, DVD+R, DVD-R DL, DVD+R DL
Optical disc diameter	120 mm
Publishing speed (CD)	30 discs/hour
Publishing speed (DVD)	17 discs/hour
Number of CD/DVD drives	2
Compatible operating systems	Windows 7, Windows 8 (32/64 bit), Windows Server 2003 (32/64bit), Windows Server 2008 (32/64bit), Windows Server 2012 (64bit), Windows Vista, Windows XP
Print speed (speed mode)	60 discs/hour
Print speed (quality mode)	42 discs/hour
Print resolution (speed mode)	1440 x 1440 DPI
Print resolution (quality mode)	1440 x 720 DPI
CD write speed	40 x
DVD-R write speed	12 x
Ethernet LAN (RJ-45) ports	1
Ethernet LAN	Yes
Pallet width	800 mm
Pallet height	1011 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	6 pc(s)
Quantity per pallet layer	2 pc(s)

Weight and Dimensions

Package depth	725 mm
Package height	525 mm
Package weight	29200 g
Dimensions (WxDxH)	730 x 530 x 522 mm
