Epson DiscProducer PP-100N User Manual

71
Publishing Discs
External Output Mode
You can select Stacker 3 or Stacker 4 as the output stacker. If you select Stacker 4 as the output stacker, you can easily
take out published discs without even having to pause a job during publishing.
The External Output Mode allows you to use the product in the following ways according to the application.
• Loading a different type of disc into each stacker
If, for example, CD-Rs are loaded in Stacker 1 and DVD-Rs are loaded in Stacker 2, a user can just select a stacker as
necessary to publish the required discs without having to change the discs.
• Continuous publishing of the same type of disc
If the same type of discs are loaded in Stacker 1 and Stacker 2 and [Auto] is selected for the input stacker setting, up to
100 CDs/DVDs can be continuously published by taking out published discs without replenishing discs. Up to 1000
CDs/DVDs can be continuously published in a single job by replenishing discs and taking out published discs.
1
23
4
1
23
4
1
23
4
1
23
4
1
23
4
Blank discs
Published discs
Blank discs
Published discs
Published discs
Published discs
Blank discs
Blank discs
1
23
4
1
23
4
1
23
4
Blank discs
Blank discs
Published discs
Blank discs
Published discs
Blank discs

Epson DiscProducer PP-100N Specifications

General

Capacity	50 discs
Interface	Ethernet
Product color	Black, Grey
Printing colors	Black, Cyan, Light cyan, Light magenta, Magenta, Yellow
Country of origin	China
Quantity per pack	1 pc(s)
Media types supported	CD-R, DVD-R, DVD+R, DVD-R DL, DVD+R DL
Optical disc diameter	120 mm
Publishing speed (CD)	30 discs/hour
Publishing speed (DVD)	17 discs/hour
Number of CD/DVD drives	2
Compatible operating systems	Windows 7, Windows 8 (32/64 bit), Windows Server 2003 (32/64bit), Windows Server 2008 (32/64bit), Windows Server 2012 (64bit), Windows Vista, Windows XP
Print speed (speed mode)	60 discs/hour
Print speed (quality mode)	42 discs/hour
Print resolution (speed mode)	1440 x 1440 DPI
Print resolution (quality mode)	1440 x 720 DPI
CD write speed	40 x
DVD-R write speed	12 x
Ethernet LAN (RJ-45) ports	1
Ethernet LAN	Yes
Pallet width	800 mm
Pallet height	1011 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	6 pc(s)
Quantity per pallet layer	2 pc(s)

Weight and Dimensions

Package depth	725 mm
Package height	525 mm
Package weight	29200 g
Dimensions (WxDxH)	730 x 530 x 522 mm
