Epson DiscProducer PP-100N User Manual

20
Opening the disc cover
1
If the disc cover is locked, unlock it.
See “Unlocking the disc cover” on page 19 in this guide for the procedure to unlock the lock.
2
Hold the handle, and open the disc cover in the direction indicated by the arrow in the
illustration below.
Closing the disc cover
Hold the handle, and close the disc cover in the direction indicated by the arrow in the
illustration below.
• Do not open the disc cover while a job is being processed (while the BUSY LED flashes).
This could adversely affect the writing or printing quality.
• If you open the disc cover while a job is being processed, an alarm beep sounds and
the status of the current job becomes Standby. If you close the disc cover, job
processing resumes automatically.
• If a job is being processed, first pause the job and then open the disc cover. See
“Pausing jobs” on page 108 in this guide for the procedure to pause a job.
• To ensure safety during arm operation, never insert your hands.
• Do not operate any stackers while the arm is moving. This could damage the arm.

Epson DiscProducer PP-100N Specifications

General

Capacity	50 discs
Interface	Ethernet
Product color	Black, Grey
Printing colors	Black, Cyan, Light cyan, Light magenta, Magenta, Yellow
Country of origin	China
Quantity per pack	1 pc(s)
Media types supported	CD-R, DVD-R, DVD+R, DVD-R DL, DVD+R DL
Optical disc diameter	120 mm
Publishing speed (CD)	30 discs/hour
Publishing speed (DVD)	17 discs/hour
Number of CD/DVD drives	2
Compatible operating systems	Windows 7, Windows 8 (32/64 bit), Windows Server 2003 (32/64bit), Windows Server 2008 (32/64bit), Windows Server 2012 (64bit), Windows Vista, Windows XP
Print speed (speed mode)	60 discs/hour
Print speed (quality mode)	42 discs/hour
Print resolution (speed mode)	1440 x 1440 DPI
Print resolution (quality mode)	1440 x 720 DPI
CD write speed	40 x
DVD-R write speed	12 x
Ethernet LAN (RJ-45) ports	1
Ethernet LAN	Yes
Pallet width	800 mm
Pallet height	1011 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	6 pc(s)
Quantity per pallet layer	2 pc(s)

Weight and Dimensions

Package depth	725 mm
Package height	525 mm
Package weight	29200 g
Dimensions (WxDxH)	730 x 530 x 522 mm
