Epson DiscProducer PP-100N User Manual

64
Input Stacker Allows you to select the stacker where the blank discs are set.
Output Stacker Allows you to select the stacker to which to output published discs.
Label Type
Allows you to select the type of disc label to be printed.
If you print on the matte label type of Epson specified discs, select [CD/DVD
Premium Label].
Mode
Setting
Color/Black Select [Color] to print in color, and select [Black] for monochrome printing.
Quality/
Speed
1: Print quality is the priority.
2: Printing speed is the priority.
This is set to [1] if [Label Type] is set to [EPSON Specified CD/DVD Label].
High Speed
(Bidirectional
printing)
If you check this, the printing speed increases because it prints when the
print head is moving either left or right.
Uncheck this to print in a single direction, which improves the print quality.
However, the printing speed slows down.
Color
Settings
Click this to display the [Color Settings] screen (see page 122 in this guide).
Allows you to set the print colors.
Label Size
Allows you to select from among the following label sizes from commercially
available software.
• Standard: Outside Diameter 116.0 mm, Inside Diameter 45.0 mm
• Wide: Outside Diameter 116.0 mm, Inside Diameter 25.5 mm
• User defined label size: Allows you to set a custom size
Copies Allows you to specify the number of copies to write/print. (0 to 1000)
Ink Levels Shows the approximate level of ink remaining in the ink cartridges.
Drying Time
Allows you to set the time it takes to dry the ink on the discs in the printer tray
after label printing is finished.
Print Preview
Select this checkbox to confirm an image of the printing results on screen
before printing when you print from commercially available software.

Epson DiscProducer PP-100N Specifications

General

Capacity	50 discs
Interface	Ethernet
Product color	Black, Grey
Printing colors	Black, Cyan, Light cyan, Light magenta, Magenta, Yellow
Country of origin	China
Quantity per pack	1 pc(s)
Media types supported	CD-R, DVD-R, DVD+R, DVD-R DL, DVD+R DL
Optical disc diameter	120 mm
Publishing speed (CD)	30 discs/hour
Publishing speed (DVD)	17 discs/hour
Number of CD/DVD drives	2
Compatible operating systems	Windows 7, Windows 8 (32/64 bit), Windows Server 2003 (32/64bit), Windows Server 2008 (32/64bit), Windows Server 2012 (64bit), Windows Vista, Windows XP
Print speed (speed mode)	60 discs/hour
Print speed (quality mode)	42 discs/hour
Print resolution (speed mode)	1440 x 1440 DPI
Print resolution (quality mode)	1440 x 720 DPI
CD write speed	40 x
DVD-R write speed	12 x
Ethernet LAN (RJ-45) ports	1
Ethernet LAN	Yes
Pallet width	800 mm
Pallet height	1011 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	6 pc(s)
Quantity per pallet layer	2 pc(s)

Weight and Dimensions

Package depth	725 mm
Package height	525 mm
Package weight	29200 g
Dimensions (WxDxH)	730 x 530 x 522 mm
