1. Remove the gear cover from the back of the high-capacity
cut-sheet feeder by pressing down the tab and pulling the
cover backward. Store it in a safe place.
2. Hold the single-bin cut-sheet feeder in both hands. Fit the
notches in the single-bin cut-sheet feeder over the mounting
posts on the back of the high-capacity cut-sheet feeder.
3. Lock the two cut-sheet feeders together by pushing firmly on
the tab locks.
To install the double-bin cut-sheet feeder on your printer, see
“Installing an optional cut-sheet feeder” on page 4-5.
G4-12-2
G4-13-1
G4-13-2
4
Gentian Rev.c
A5 size Chapter 4
97/06/20 pass 0
Printing on Single Sheets
4-15
