Epson FX 880 - Using the Tractor in the Rear Push Position; Installing the Tractor in the Rear Push Position

Using the Tractor in the Rear Push Position
Installing the tractor in the rear push position
Before installing the tractor in the rear push position, remove
it from its current position. If the tractor is in the front push
position, remove it by pressing the lock tabs while lifting it out.
If the tractor is in the pull position, remove it as described on
page 3-20.
Note:
❑
The tractor is installed in the rear push position when the printer
is shipped.
❑
Thick paper, such as multi-part forms with five or six parts,
requires a straight paper path to avoid paper jams. When printing
on thick continuous paper, use the tractor in the front push
position.
1. Make sure the printer is turned off.
2. Lift the paper guide up and off the printer.
G4
L
Gentian Rev.c
A5 size Chapter 3
97/07/04 pass 2
3-12
Printing on Continuous Paper
