Using the Tractor in the Front Push Position
Installing the tractor in the front push position
Before installing the tractor in the front push position, remove
it from its current position. If the tractor is in the rear push
position, remove the paper guide and then press the lock tab
while lifting it out. If the tractor is in the pull position, remove
it as described on page 3-20.
Note:
The tractor is installed in the rear push position when the printer is
shipped.
1. Make sure the printer is turned off.
2. Open the front cover.
If the optional front sheet guide is installed, remove it by grasping
the fins on both sides and pulling it slightly up and away from
the printer.
G4-18
L
Gentian Rev.c
A5 size Chapter 3
97/07/04 pass 2
3-6
Printing on Continuous Paper
